01

Masoneilan 78000

The Masoneilan® 78000 Lincoln log is a rugged valve built and designed specifically for cavitation control.

  • NPS 1” to 12”
  • 600-2500 fanged ANSI class rating available. BW or SW are also available.
  • Available body constructions are Carbon steel, stainless steel, or chrome-moly.
  • Linear flow characteristic.
  • Class VI is available upon request.

02

Masoneilan 21000

The Masoneilan® 21000 series is a rugged designed globe valve featuring a top guided plug.

  • NPS ¾” to 8”
  • 150 -2500 flanged ANSI class rating available. BW or SW. Threaded connections also available in ¾” to 2”.
  • Available body constructions are carbon steel, stainless steel, or chrome-moly.
  • Linear or equal percent flow characteristics.

03

Masoneilan 35002 Series Camflex

The Masoneilan® 35002 Camflex is a rotary valve with an offset eccentric plug. Great for basic water service to severe erosive service.

  • NPS 1” thru 16”
  • 150-600 flanged ANSI class ratings available. 150-600 flangeless options available. screwed NPT available in sizes 1” thru 2”
  • Available body constructions are carbon steel, stainless steel, and high nickel alloy.
  • Linear flow characteristic.

04

Masoneilan 41005

The Masoneilan® 41005 series valve is a rugged heavy-duty valve that works great with high pressure drops and temperature variations. This valve features balanced trim configurations.

  • NPS 2” thru 24”
  • 150-2500 flanged ANSI class ratings. BW or SW welded options. Screwed NPT available in 2”.
  • Available body constructions are carbon steel, stainless steel, or chrome-moly.
  • Linear or equal percent flow characteristics.

05

Masoneilan 10000

The Masoneilan® 10000 Series valve is a double port globe valve that’s excellent for high pressure drops and has a large flow area suitable for dirty fluid processes.

  • NPS 2” thru 24”
  • 150-1500 flanged ANSI class ratings. BW or SW welded options. screwed NPT available in ¾” thru 2”.
  • Available body constructions include carbon steel, stainless steel, or chrome-moly.
  • Equal percent, linear, or quick open flow characteristics.
